Bakery equipment
Bakery equipment
Doughmaker ZZ-80

Doughmaker ZZ-80

Product parameters
Model:ZZ-80
Rated voltage:3N-380V/50Hz
Rated power:2.2/3.3kW/h
Mixer speed:125/250r/min Mixing drum speed:10/20r/min
Package size:1130×660×1280mm
Mixer capacity:84L
Production capacity: 35kg flour
 Barrel thickness:2.5mm

DoughmakerZZ-60

DoughmakerZZ-60

Product parameters
Model:ZZ-60
Rated voltage:3N-380V/50Hz
Rated power:1.5/2.4kW/h
Mixer speed:115/230r/min
Mixing drum speed:10/20r/min
Package size:1035×610×1150mm
Mixer capacity:68L
Production capacity: 25kg flour
Barrel thickness:2.5mm

Doughmaker ZZ-240

Doughmaker ZZ-240

Product parameters
Model:ZZ-240
Rated power:4/7.5kW
Rated voltage:380V/50Hz
Capacity:240L
Mixer speed:125/250r/min
Mixing drum:10/20r/min
Production capacity: 100kg dough
Barrel depth thickness:3.5mm
Panel: computer panel
Package size:1505×890×1700mm

Blender B-40

Blender B-40

Product parameters
Model:B-40
Rated power:2kW/h
Rated voltage:380V/50Hz
Mixer speed:65/102/296r/min
Overall dimension:550×650×1060mm
Capacity:50L
Throughput:6-8kg
Net weight:150kg
Package size:700×680×1170mm

Blender B-30

Blender B-30

Product parameters
Model:B-30
Rated power:1.5kW/h
Rated voltage:220V/50Hz
Mixer speed:110/200/420r/min
Overall dimension:520×430×890mm
Capacity:30L
Throughput:3-6kg
Net weight:103kg
Package size:620×530×1200mm

Doughmaker 120T

Doughmaker 120T

Product parameters
model:120T
Rated voltage: three-phase/50Hz-60Hz
Rated power: 4.5kW mixing hook/0.75kW mixing drum
Mixer speed:125/250r/min
Product size:1120*750*1300mm
Cylinder size: inner diameter 672mm,Internal depth 389mm
Production capacity: 50kg flour/80kg dough
Cylinder speed: the first 17.2 rpm/divide,The second 17.2 turns/divide
Net weight: 385 kg

Doughmaker 80T

Doughmaker 80T

Product parameters
Model:80T
Rated voltage: three-phase/50Hz-60Hz
Rated power: 4.5kW mixing hook/0.75kW mixing drum
Mixer speed:125/250r/min
Product size:1120*750*1300mm
Cylinder size: inner diameter 672mm,Internal depth 389mm
Production capacity: 50kg flour/80kg dough
Cylinder speed: the first 17.2 rpm/Minutes,The second 17.2 turns/divide
  Net weight: 385 kg

Doughmaker 50T

Doughmaker 50T

Product parameters
Model:50T
Rated voltage: three-phase/50Hz-60Hz
Rated power: 3kW mixing hook/0.7kW mixing drum
Mixer speed:135/270r/min
Product size:930*600*1250mm
Cylinder size: inner diameter 546mm,Internal depth 350mm
Production capacity: 25kg flour/50kg dough
Cylinder speed: the first 17.8 rpm/divide，The second 17.8 turns/divide
Net weight: 320 kg

DoughmakerZZ-40

DoughmakerZZ-40

Product parameters
model:ZZ-40
Rated voltage:3N-380V/50Hz
Rated power:0.85/1.1kW/h
Mixer speed:114/230r/min
Mixing drum speed:12/24r/min
Overall dimension:910×530×1040mm
Mixer capacity:48L
Throughput:16kgwheat flour
Barrel thickness:2.0mm

BlenderB-50

BlenderB-50

Product parameters
Model:B-50
Rated power:2.2kW/h
Rated voltage:380V/50Hz
Mixer speed:74/141/277r/min
Overall dimension:610×650×1350mm
Capacity:50L
Throughput:5-9kg
Net weight:385kg
Package size:725×675×1270mm

Blender 25T

Blender 25T

Product parameters
Model:25T
Capacity:12.5 kg flour/25 kg dough
Hook speed: the first speed is 140rpm，The second speed is 280rpm
Cylinder size: diameter 442mm, depth298mm
Power: mixing hook2.2kW
Cylinder speed: the first speed is 12.8RPM, the second speed is 25.5PRM
Weight: 130 kg
Size:823*550*1030mm

Doughmaker ZZ-120

Doughmaker ZZ-120

Product parameters
Model:ZZ-120
Rated voltage:3N-380V/50Hz
Rated power:3.0/4.5kW/h
Mixer speed:125/250r/min
Mixing drum speed:10/20r/min
Package size:1210×790×1310mm
Mixer capacity:122L
Production capacity: 50kg flour
Barrel thickness:3.5mm
